- OSD menu is available
- 15.24cm (6) half Metal Body construction, IP66
- AHD/TVI/CVI/CVBS selectable
- Keep original analogue system
- Real-time transmission, lossless video
- Long-distance transmission up to 500 meters
| General | |
| Sensor | 1/3″ CMOS 2MP NVP2441+SONY323 |
| Output pixel | 1920x1080p/30fps,1920x1080p/25fps |
| Lens | 20X, F=4.7-96.3mm |
| BLC | Support |
| AGC | Auto/Manual |
| WB | Indoor/Outdoor/Auto/Manual |
| S/N Ratio | ≥50dB |
| WDR | DWDR |
| Auto Control IR LED | PWM |
| IR Distance | Up to 150 meters |
| LED | 7PCS IR LED + 2PCS Laser LED |
| Rotation Range | Pan: 0°~360°, Tilt: 0°~93° |
| Rotation Speed(High) | Pan: 0~45°/s, Tilt:0~30°/s |
| Auto Flip | Horizontal 180°, Vertical 93° |
| Preset Points | 220pcs preset (Dwell time 01-60s interval available) |
| A-B Scan | User-programmable (scan speed 1-64 levels setting available) |
| Guard Tours | 3 groups (Max.16 points, dwell time user selectable) |
| Video interface output | AHD/TVI/CVI/CVBS selectable |
| Communication Mode | RS485 (+/-) / coaxial cable |
| Operating Temperature | -40°C~+60°C |
| Power | DC12V 3A |
| Power Consumption | ≤25W |
| Lightning Protection | Transient voltage 6000V |
