- Key Features
- Maximum Boom Length – Up to 6m retractable aluminium boom
- Fast Operation – Opening time: 3-6 seconds for smooth traffic control
- Reliable Power Supply – 220V ±10% with IP55 protection grade
- 100% Duty Cycle – Designed for continuous operation
- Remote Control – Operates up to 10-20 meters distance
- Manual Override – Allows manual operation in case of power failure
- External Integration – Supports vehicle detectors for enhanced security
- LED Flashing Light – Built-in double LED lights for better visibility
- Adopt crank connecting rod mechanism driving, reduce the mechanical failure, low noise, no pollution, no need to maintain.
- Remote control distance up to 10 ~ 20 meters, can control way of the brake switch form at any time, ensure the channel unimpeded
- The balance of the special institutions, always covers up the vertical rod, rod level, and smooth, it can adjust the length according to the free brake rod
| General | |
| Boom Size | Up to 6Mtr (With Retraceable Feature) |
| Frequency | 50/60Hz |
| Open Time | 3 ~ 6 sec |
| Motor | Electro-Mechanical |
| Voltage | 220V 10% |
| Controller | Microprocessor Based |
| Interface | Traffic Light less than 10A |
| Body | Weather Proof with anti-corrosion treatment |
| Other Accessories | Operating Switch & Boom Stand / Remote |
| Boom | Motion Control By Balanced Spring System |
| IP Grade | IP55 |
| Remote Distance | 10 ~ 20mtr |
| Optional | Access Control System. RF Reader, Photo Cell |
| Duty Cycle | 100% |
| LED Indicator | Red & Green for Opening I Close Status |
