Grandlink GLK14 fiber optic fusion splicer splicing machine

Grandlink GLK14 Fiber Optic Splicing Machine with 5-Inch Touch Screen & 420X Zoom

Name: Grandlink GLK14 Fiber Optic Splicing Machine with 5-Inch Touch Screen &amp; 420X Zoom
SKU: 22844
Availability: InStock

Original price was: ₹135,000.00.Current price is: ₹79,950.00.

🔹 High Magnification (420X) – Ultra-clear core alignment with naked-eye visibility
🔹 5” HD Capacitive Touchscreen – Dual control via touch and key buttons
🔹 6200mAh Battery – Supports up to 420 splicing & heating cycles
🔹 Fast Boot & Operation – 3s boot, 6–7s splicing, 18s heating
🔹 Voice Broadcast Function – Real-time voice prompts to boost efficiency
🔹 Modular Expandability – Bluetooth, Wi-Fi, OTDR, GPS, OPM, VFL, IoT & more
🔹 Massive Storage – Save 20,000 splicing records & 2000 images
🔹 Multifunctional Fixture – Compatible with G651–G657 fiber types
🔹 Robust Field Design – Shock-resistant, weatherproof, high-altitude support
🔹 Graphical UI – Easy maintenance and operation via GUI interface

Compare

Categories: Fiber Testing Measurements Devices, SPLICING MACHINE Tags: Core Alignment Fusion Splicer, Fiber cable fusion machine, Fiber jointing machine for FTTH, Fiber optic fusion splicer, Fiber optic splicer for FTTH deployment, Fiber splicer for telecom networks, Fiber splicer with auto core alignment, FTTH fiber jointing tool, FTTH fiber splicing machine, Fusion splicer for field engineers, Fusion splicer for ISP, Fusion splicer with touchscreen, Fusion splicing machine for BSNL / JioFiber, GLK series fiber optic tools, GLK-14 fiber jointing machine, GLK-14 fusion splicer, Grandlink fiber splicer, Grandlink GLK-14, Grandlink GLK-14 Fiber Optic Fusion Splicer, Grandlink GLK-14 splicer India, Grandlink splicing machine for optical fiber, High Precision Fiber Splicer, Optical Fiber Splicing Machine, Portable fiber fusion splicer, SPLICING MACHINE, Splicing machine for fiber optic cable, Telecom grade fusion splicing tool

Description
Reviews (0)

Grandlink GLK14 fiber optic fusion splicer splicing machine

The Grandlink GLK14 Splicing Machine is a professional-grade fiber fusion solution designed for demanding telecom, FTTH, and field installation environments. With 420X image magnification and a 5-inch HD capacitive touch screen, it ensures precise fiber alignment and seamless operation—even in harsh conditions.

Powered by an industrial-grade processor and supported by 6200mAh battery life, it can perform up to 420 splice-and-heat cycles on a single charge. The machine supports modular expansion, including Bluetooth, WiFi, GPS, OTDR, VFL, OPM, 10G PON, and even Laser Ranging—making it a future-ready splicing machine built for high-performance fiber networks.

It features a voice-guided interface, real-time discharge correction, and double touch operation for user-friendly control. The multi-functional clamp accommodates multiple fiber types, and the data capacity allows storage of 20,000 splice records and 2000 images, making the GLK14 splicing machine perfect for long-term project tracking and advanced diagnostics.

Specifications

Specification	Details
Model	GLK14
Splice Time	6–7 seconds
Heating Time	18 seconds (adjustable)
Motors	4 Motors
Image Magnification	420X
Display	5″ HD Capacitive Touch Screen
Processor	Industrial-grade CPU
Battery Capacity	6200mAh (420 splice/heat cycles)
Clamp Type	3-in-1 Multifunctional Fixture
Welding Modes	500 Programs
Heating Modes	200 Programs
Memory	20,000 records + 2000 images
Splice Loss	SM: 0.02dB, MM: 0.01dB, NZDS: 0.04dB
Return Loss	≥60dB
Electrode Life	≥5000 discharges
Auto Heating	Supported
Discharge Calibration	Real-time + Manual
Languages	Multiple (User-selectable)
Operating Altitude	0–5000m
Working Temp/Wind	-20℃ to +50℃ / 15m/s Wind Speed
Humidity	0–95% (non-condensing)
Power Supply	AC100–240V / DC15–19V
Startup Time	3 Seconds
USB Function	USB 2.0 Port + Reverse Charging
Weight	1.88 kg (with battery)
Dimensions	150 × 146 × 145 mm
